316 and 316/L (UNS S31600 & S31603) are molybdenum-bearing austenitic stainless steels. The 316/316L stainless steel bar, rod and wire alloy also offer higher creep, stress to rupture and tensile strength at elevated temperatures, in addition to excellent corrosion resistance and strength properties. 316/L refers to the lower carbon content to allow for greater corrosion protection when welding.
Austenitic steels have austenite as their primary phase (face centered cubic crystal). These are alloys containing chromium and nickel (sometimes manganese and nitrogen), structured around the Type 302 composition of iron, 18% chromium, and 8% nickel. Austenitic steels are not hardenable by heat treatment. The most familiar stainless steel is probably Type 304, sometimes called T304 or simply 304. Type 304 surgical stainless steel is austenitic steel containing 18-20% chromium and 8-10% nickel.
Available shapes: Hexes, Rounds, Square| SKU | Description | Manufacture Method | Diameter | Shape | Specification |
|---|---|---|---|---|---|
| 316/L CD S/S ROD .3125 SQ | HOT ROLLED ANNEALED & PICKLED | 0.3125 | STEEL BAR SQUARE | ASTM A479 18 ASTM A276 16 | |
| 316/316L CDA S/S ROD .3125 DIA | Air Melt | 0.3125 | STEEL ROD/BAR ROUND | AMS5648 AMS5653 | |
| 54807 | 316/316L CDA S/S ROD .4375 DIA | Air Melt | 0.4375 | STEEL ROD/BAR ROUND | AMS5648 AMS5653 |
| 49334 | 316/L SS .9375 HEX x12'R/L | HOT ROLLED ANNEALED & PICKLED | 0.9375 | STEEL ROD/BAR HEX | AMS5648 AMS5653 |
| 36207 | 316/L BAR A479 .5625 HEX | HOT ROLLED ANNEALED & PICKLED | 0.5625 | STEEL ROD/BAR HEX | AMS5648 AMS5653 |
| 07881 | 316/316L S/S ROD 1.1875 DIA | Air Melt | 1.1875 | STEEL ROD/BAR ROUND | AMS5648 AMS5653 |
| 93023 | 316/L S/S GAUER BAR .1875 X 3.0000 | HOT ROLLED | 0.1875 | STEEL BAR RECTANGULAR | ASTM A240 ASTM A276 16 |
| 07434 | 316/L S/S GAUER BAR .1875 X 2.0000 | HOT ROLLED | 0.1875 | STEEL BAR RECTANGULAR | ASTM A240 ASTM A276 16 |
| 07432 | 316/L S/S GAUER BAR .1875 X 1.0000 | HOT ROLLED | 0.1875 | STEEL BAR RECTANGULAR | ASTM A276 16 ASTM A240 |
| 07755 | 316/316L CDA S/S ROD .1875 DIA | Air Melt | 0.1875 | STEEL ROD/BAR ROUND | AMS5648 AMS5653 |
| 316 | 316/L | |
|---|---|---|
| Minimum Properties | ||
| Tensile Strength , psi | 75,000 | 70,000 |
| Yield Strength, psi | 30,000 | 25,000 |
| Elongation | 40% | 40% |
| Hardness | Rb 95 max | Rb 95 max |
| Chemistry | ||
| Carbon( C) | .08 max | 0.03 max |
| Chrome (Cr) | 16.0- 18.0 | 16.0- 18.0 |
| Manganese (Mn) | 2.00 max | 2.00 max |
| Nickel ( Ni) | 10.0- 14.0 | 10.0- 14.0 |
| Phosphorus (P) | .045 max | .045 max |
| Sulphur (S) | .030 max | .030 max |
| Silicon (Si) | 0.75 max | 0.75 max |
| Molydenum (Mo) | 2.00-3.00 | 2.00-3.00 |
