304 and 304/L (UNS S30400 & UNS S30403) are austenitic alloys of stainless steel bars. These alloys are the most familiar and most frequently used alloys in the stainless steel family. The L in 304/L refers to a lower carbon content to allow for greater corrosion protection when welding.
Austenitic steels have austenite as their primary phase (face centered cubic crystal). These are alloys containing chromium and nickel (sometimes manganese and nitrogen), structured around the Type 302 composition of iron, 18% chromium, and 8% nickel. Austenitic steels are not hardenable by heat treatment. The most familiar stainless steel is probably Type 304, sometimes called T304 or simply 304. Type 304 surgical stainless steel is austenitic steel containing 18-20% chromium and 8-10% nickel.
Available shapes: Hexes, Rounds, Square| SKU | Description | Manufacture Method | Diameter | Shape | Specification |
|---|---|---|---|---|---|
| 75930 | 304 S/S GAUER BAR .3125 X 2.0000 | GAUER | 0.3125 | STEEL BAR RECTANGULAR | A240 CHEMISTRY ASTM A276 16 |
| 07769 | 304/304L CDA S/S ROD .3125 DIA | Air Melt | 0.3125 | STEEL ROD/BAR ROUND | AMS5639 ASTM A276 16 |
| 07776 | 304/L CDA S/S ROD .4375 DIA | Air Melt | 0.4375 | STEEL ROD/BAR ROUND | AMS5639 ASTM A276 16 |
| 51767 | 304/L S/S BAR 7/16 HEX | HOT ROLLED ANNEALED & PICKLED | 0.4375 | STEEL ROD/BAR HEX | AMS5639 ASTM A276 16 |
| 07868 | 304/304L S/S ROD .8125 DIA | Air Melt | 0.8125 | STEEL ROD/BAR ROUND | AMS5639 ASTM A276 16 |
| 51754 | 304/304L CDA/CF S/S ROD .5625 DIA | Air Melt | 0.5625 | STEEL ROD/BAR ROUND | AMS5639 ASTM A276 16 |
| 53203 | 304/304L ROD .5625 HEX | HOT ROLLED ANNEALED & PICKLED | 0.5625 | STEEL ROD/BAR HEX | AMS5639 ASTM A276 16 |
| 07738 | 304/304L CF S/S ROD 1.1875 DIA | Air Melt | 1.1875 | STEEL ROD/BAR ROUND | AMS5639 ASTM A276 16 |
| 89315 | 304 S/S GAUER BAR .1875 X .7500 | GAUER | 0.1875 | STEEL BAR RECTANGULAR | A240 CHEMISTRY ASTM A276 16 |
| 10767 | 304 S/S GAUER BAR .1875 X 6.0000 | GAUER | 0.1875 | STEEL BAR RECTANGULAR | A240 CHEMISTRY ASTM A276 16 |
| 304 | 304/L | |
|---|---|---|
| Minimum Properties | ||
| Tensile Strength , psi | 75,000 | 70,000 |
| Yield Strength, psi | 30,000 | 25,000 |
| Elongation | 40% | 40 |
| Hardness | Rb 92 max | Rb 92 max |
| Chemistry | ||
| Carbon( C) | .08 max | 0.03 max |
| Chrome (Cr) | 18.0-20.0 | 18.0-20.0 |
| Manganese (Mn) | 2.00 max | 2.00 max |
| Nickel ( Ni) | 8.0 - 10.50 | 8.0 - 12.00 |
| Phosphorus (P) | .045 max | .045 max |
| Sulphur (S) | .030 max | .030 max |
| Silicon (Si) | 0.75 max | 0.75 max |
