15-5 is a variant of the older 17-4 chromium-nickel-copper precipitation hardening stainless steel. Both alloys exhibit high strength and moderate corrosion resistance. High strength is maintained to approximately 600 degrees F. The 15-5 alloy was designed to have greater toughness than 17-4. This improved toughness is achieved by reduced delta ferrite content and control of inclusion size and shape.
| SKU | Description | Manufacture Method | Diameter | Shape | Specification |
|---|---|---|---|---|---|
| 21922 | 15-5 PH RD 5659 COND A 7/16 RD | NOT REQUIRED | 0.4375 | STEEL ROD/BAR ROUND | AMS5659 |
| 53332 | 15-5PH VAC AMS5659 TYP I .8125 DIA | NOT REQUIRED | 0.8125 | STEEL ROD/BAR ROUND | AMS 5659 |
| 21924 | 15-5 PH RD 5659 COND A 9/16 RD | HOT ROLLED ANNEALED & PICKLED | 0.5625 | STEEL ROD/BAR ROUND | AMS5659 |
| 50696 | 15-5PH ESR AMS5659 1.250RD NON-DFAR | ELECTRIC SLAG REMELT | 1.2500 | STEEL ROD/BAR ROUND | AMS5659 |
| 50425 | 15-5PH VAR AMS5659 1.250RD NON-DFAR | VACUUM ARC REMELT | 1.2500 | STEEL ROD/BAR ROUND | AMS5659 |
| 21942 | 15-5PH VAC AMS5659 TYP I 1.250 DIA | NOT REQUIRED | 1.2500 | STEEL ROD/BAR ROUND | AMS5659 |
| 50692 | 15-5PH ESR AMS5659 1.00 RD NON-DFAR | ELECTRIC SLAG REMELT | 1.0000 | STEEL ROD/BAR ROUND | AMS5659 |
| 50422 | 15-5PH VAR AMS5659 1.00 RD NON-DFAR | VACUUM ARC REMELT | 1.0000 | STEEL ROD/BAR ROUND | AMS5659 |
| 21932 | 15-5PH VAC AMS5659 TYP I 1.000 DIA | NOT REQUIRED | 1.0000 | STEEL ROD/BAR ROUND | AMS5659 |
| 50702 | 15-5PH ESR AMS5659 1.500RD NON-DFAR | ELECTRIC SLAG REMELT | 1.5000 | STEEL ROD/BAR ROUND | AMS5659 |
| 15-5 PH Stainless Steel Condition A (annealed) | |
|---|---|
| Minimum Properties | |
| Ultimate Tensile Strength, psi | 161,000 |
| Yield Strength, psi | 140,000 |
| Elongation | 7.6% |
| Rockwell Hardness | C35 |
| Chemistry | |
| Iron (Fe) | 71.91 - 79.85% |
| Carbon (C) | 0.07% max |
| Chrome (Cr) | 14 - 15.5% |
| Manganese (Mn) | 1% max |
| Niobium (Nb) + Tantalum (Ta) | 0.15 - 0.45% max |
| Nickel (Ni) | 3.5 - 5.5% |
| Phosphorus (P) | 0.04% max |
| Sulphur (S) | 0.03% min |
| Silicon (Si) | 1% max |
