303 STAINLESS STEEL BAR

services

303 (UNS 30300) stainless steel bars were developed for machining. Type 303 has a higher concentration of sulfur reducing the drag on cutting tools. It allows greater machining speeds and lower production costs. The alloy is useful whenever a need arises for good corrosion resistance and considerable machining is required.

Austenitic steels have austenite as their primary phase (face centered cubic crystal). These are alloys containing chromium and nickel (sometimes manganese and nitrogen), structured around the Type 302 composition of iron, 18% chromium, and 8% nickel. Austenitic steels are not hardenable by heat treatment. The most familiar stainless steel is probably Type 304, sometimes called T304 or simply 304. Type 304 surgical stainless steel is austenitic steel containing 18-20% chromium and 8-10% nickel.

SKU Description Manufacture Method Diameter Shape Specification
75868 HOT ROLLED ANNEALED & PICKLED ASTM A582
07797 303 CDA S/S ROD .3125 DIA Air Melt 0.3125 STEEL ROD/BAR ROUND AMS5640 ASTM A582
07812 303 CDA S/S ROD .4375 DIA Air Melt 0.4375 STEEL ROD/BAR ROUND AMS5640 ASTM A582
49297 303 SS .8125 HEX x 12'R/L HOT ROLLED ANNEALED & PICKLED 0.8125 STEEL ROD/BAR HEX AMS5640 ASTM A582
07854 303 CDA S/S ROD .5625 DIA Air Melt 0.5625 STEEL ROD/BAR ROUND AMS5640 ASTM A582
303 CDA S/S ROD .1875 DIA Air Melt 0.1875 STEEL ROD/BAR ROUND AMS5640 ASTM A582
07784 303 CF S/S ROD 1.2500 DIA Air Melt 1.2500 STEEL ROD/BAR ROUND AMS5640 ASTM A582
07768 303 CF S/S ROD 1.00 DIA Air Melt 1.0000 STEEL ROD/BAR ROUND AMS5640 ASTM A582
07295 303 S/S ROD 1.0000 HEX HOT ROLLED ANNEALED & PICKLED 1.0000 STEEL ROD/BAR HEX AMS5640 ASTM A582
07801 303 CF S/S ROD 1.5000 DIA Air Melt 1.5000 STEEL ROD/BAR ROUND AMS5640 ASTM A582
Typical Chemical Properties
Minimum Properties
Tensile Strength , psi 85,000
Yield Strength, psi 45,000
Elongation 50%
Hardness Rb 180
Chemistry
Carbon( C) .15 max
Chrome (Cr) 17.0- 19.0
Manganese (Mn) 2.0 max
Nickel ( Ni) 8.0 -10.0
Phosphorus (P) 0.20 max
Sulphur (S) .15 min
Silicon (Si) 1.00 max
