6063 ALUMINUM BAR

6063 (UNS A96063) is an aluminum bar that offers good extrudability and high quality surface. This alloy is used for standard architectural shapes, custom solids and heatsinks. Also used for electrical applications in T5, T52 & T6 due to its electrical conductivity.

6063 is commonly referred to as an architectural alloy. It has a high resistance to corrosion with excellent finishing characteristics. 6063 has average machinability and forming hot or cold is acceptable. Also due to its conductivity it is utilized in electrical substations. Commonly used in the manufacture of pipe railings, furniture, windows, stair rails, and in pipe railing.

Available shapes: Flats
Tempers: T5, T52, T6
Specifications: ASTM B221, AMS 4156, AMS QQ-A-200/9

SKU	Description	Manufacture Method	Temper	Diameter	Shape	Specification
17679	6063T52 AL EXT BAR .1875 X .7500	EXTRUDED	T52	0.1875	BAR RECTANGULAR	ASTM B221
04239	6063T52 AL EXT BAR .1875 X 1.000	EXTRUDED	T52	0.1875	BAR RECTANGULAR	ASTM B221
43752	6063T52 EXT B221 1.00 DIA	EXTRUDED	T52	1.0000	ROD/BAR ROUND	ASTM B221
43815	6063T52 EXT BAR B221 .500 X .750	EXTRUDED	T52	0.5000	BAR RECTANGULAR	ASTM B221
A2752	6063T5 EXT B221 .3750 DIA	EXTRUDED	T52	0.3750	ROD/BAR ROUND	ASTM B221 AMS-QQ-A-200/9
04199	6063T52 AL EXT BAR .2500 X 2.000	EXTRUDED	T52	0.2500	BAR RECTANGULAR	ASTM B221
04294	6063T52 AL EXT BAR .125 X .750	EXTRUDED	T52	0.1250	BAR RECTANGULAR	ASTM B221
04289	6063T52 AL EXT BAR .1250 X 1.250	EXTRUDED	T52	0.1250	BAR RECTANGULAR	ASTM B221
04280	6063T52 AL EXT BAR .1250 X .500	EXTRUDED	T52	0.1250	BAR RECTANGULAR	ASTM B221
04229	6063T52 AL EXT BAR .1250 X 1.500	EXTRUDED	T52	0.1250	BAR RECTANGULAR	ASTM B221

Typical Chemical Composition %

Weight %	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total
Minimum	0.20				0.45
Maximum	0.60	0.35	0.10	0.10	0.90	0.10	0.10	0.10	0.05	0.15

Typical Mechanical Properties

Temper	Tensile					Hardness
	Ultimate		Yield		Elongation	Brinell
	KSI	MPA	KSI	MPA	%
T5, T52	27	186	21	145	12	60
T6	35	241	31	214	12	73
