2024 ALUMINUM BAR

AL-2024 (UNSA902404) is an aluminum bar with cold finished or extruded aluminum wrought product providing high to moderate strength, very good machinability and weld ability with improved stress corrosion cracking resistance.

2024 is known as the “aircraft alloy” in machining rod. It is one of the most popular alloys for cold heading and roll threading applications. It has high strength and excellent fatigue resistance. It is excellent on parts where good strength –to-weight ratio is needed. Machinability is good in heat treated and annealed condition. Commonly used in aircraft structural components, truck wheels, medical instruments, and screw machine products. We stock 2024-T351, 2024-T3511, and 2024-T4.

Available shapes: Flats, squares and rounds
Tempers: T351, T3511 & T4
Specifications: ASTM B211, AMS 4120, AMS 4339, AMS-QQ-A-225/6, ASTM B221, AMS 4152, AMS 4164, AMS 4165, AMS-QQ-A-200/3

SKU	Description	Manufacture Method	Temper	Diameter	Shape	Specification
04441	2024T351 ALUM SMS ROD 1.2500 DIA	COLD FINISH	T351	1.2500	ROD/BAR ROUND	AMS4120 AMS4339
04287	2024T351 ALUM CF BAR 1.250 X 2.000	COLD FINISH	T351	1.2500	BAR RECTANGULAR	AMS4120 AMS4339
04468	2024T351 AL ROD AMS 4120 1.00 DIA	COLD FINISH	T351	1.0000	ROD/BAR ROUND	AMS4120 AMS4339
	2024T3511 BAR 1.0 X 2.0 W/.375" RC	EXTRUDED	T3511	1.0000	BAR RECTANGULAR	AMS4165 ASTM B221
35886	2024T351 ALUM CF BAR 1.000 X 1.500	COLD FINISH	T351	1.0000	BAR RECTANGULAR	AMS4120 AMS4339
04276	2024T351 ALUM CF BAR 1.000 X 2.500	COLD FINISH	T351	1.0000	BAR RECTANGULAR	AMS4120 AMS4339
	2024T351 ALUM CF BAR 1.000 X 3.000	COLD FINISH	T351	1.0000	BAR RECTANGULAR	AMS4120 AMS4339
04211	2024T351 ALUM CF BAR 1.000 X 2.000	COLD FINISH	T351	1.0000	BAR RECTANGULAR	AMS4120 AMS4339
35887	2024T351 ALUM CF BAR 1.500 X 2.000	COLD FINISH	T351	1.5000	BAR RECTANGULAR	AMS4120 AMS4339
04456	2024T351 ALUM CF ROD 5.00 DIA	COLD FINISH	T351	5.0000	ROD/BAR ROUND	AMS4120 AMS4339

Typical Chemical Composition %

Weight %	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total
Minimum			3.80	1.20	0.30
Maximum	0.50	0.50	4.90	1.80	0.90	0.10	0.25	0.15	0.05	0.15

Typical Mechanical Properties

Temper	Tensile					Hardness
	Ultimate		Yield		Elongation	Brinell
	KSI	MPA	KSI	MPA	%
T4, T351	68	469	47	324	19	120
