601 NICKEL BAR, ROD

Nickel Alloy 601 bar, rod, and wire is a nickel-chromium with an addition of aluminum that provides high mechanical properties at elevated temperatures, as well as superior resistance to oxidation, carburization, and sulfurization. It excels particularly in descaling resistance in cyclic oxidation applications with a high temperature variation.

SPECIFICATIONS:

UNS: NO6601
W. Nr./EN: 2.4851
AMS: 5870
ASME: SB 168
ASTM: B 168

Features:

Superior resistance to oxidation, carburization, and sulfurization
Excels in descaling resistance in cyclic oxidation applications with high temperature variation
High mechanical properties at elevated temperatures
Hot working is relatively easy

Applications:

Muffle furnaces
Baskets and other furnace parts
Industrial heat treatment furnace parts
Special glass-melting furnace parts
Automobile glow plug parts
Automobile exhaust gas sensor covers

SKU	Description	Manufacture Method	Diameter	Shape	Specification
06918	ALLOY 601 HF ROD ANN 1.250 DIA	HOT FINISHED	1.2500	ROD/BAR ROUND	AMS 5715
75674	ALLOY 601 HF ROD ANN 1.00 DIA	HOT FINISHED	1.0000	ROD/BAR ROUND	AMS 5715
06929	ALLOY 601 HF ROD ANN 1.500 DIA	HOT FINISHED	1.5000	ROD/BAR ROUND	AMS 5715
06915	ALLOY 601 ROD S/A .500 DIA	NOT REQUIRED	0.5000	ROD/BAR ROUND	AMS 5715
06921	ALLOY 601 HF ROD ANN 2.00 DIA	HOT FINISHED	2.0000	ROD/BAR ROUND	AMS 5715
06884	ALLOY 601 HRAP .3750 DIA	HOT ROLLED ANNEALED & PICKLED	0.3750	ROD/BAR ROUND	AMS 5715
06886	ALLOY 601 ROD .750 DIA	HOT FINISHED	0.7500	ROD/BAR ROUND	AMS 5715
06882	ALLOY 601 ROD ANN .2500 DIA	HOT FINISHED	0.2500	ROD/BAR ROUND	AMS 5715

CHEMICAL COMPOSITION, %:

	Ni	Cr	Al	C	Mn	Cu	Si	S	Fe
MIN	58.0	21.0	1.0	-	-	-	-	-	-
MAX	63.0	25.0	1.7	0.1	1.0	1.0	0.5	0.015	Bal.
